Part No HD Dia HD Height Material Thickness Material Width Min Round Tubing I.D. Max Round
Tubing I.D. Min Square
Tubing I.D. Max Square
Tubing I.D. II-050 .125 .160 .012 .170 .25 .60 .25 .60 II-071 .156 .290 .018 .210 .57 .63 .57 .63 II-130 .250 .280 .022 .250 .43 .87 .41 .87 II-132 .250 .370 .025 .312 .55 .87 .43 .87 II-133 .250 .370 .025 .375 .58 1.00 .55 1.00 II-134 .250 .500 .025 .312 .75 1.00 .75 1.00 II-135 .250 .620 .025 .312 .875 .1.50 .80 1.50 II-136 .250 .380 .018 .365 .75 1.45 .75 1.45 II-150 .312 .370 .025 .312 .55 1.00 .50 1.00 II-151 .312 .500 .025 .375 .90 1.90 .90 1.90 II-152 .312 .400 .022 .250 .62 .80 .62 .80 II-153 .312 .370 .030 .375 1.42 2.75 1.42 2.75 II-174 .375 .590 .020 .440 1.00 1.75 1.00 1.75 II-175 .365 .375 .020 .440 .80 1.40 .80 1.40 II-176 .375 .590 .030 .375 .98 2.25 .98 2.25 II-180 .375 .370 .030 .375 .60 1.12 .55 1.12 II-181 .375 .210 .030 .375 .75 1.12 .75 1.12 II-182 .375 .250 .030 .375 .70 1.40 .70 1.40 II-183 .375 .590 .030 .375 .87 1.30 .87 1.30 II-184 .375 .310 .030 .375 .67 1.38 .67 1.38 II-186 .375 .375 .020 .375 II-200 .500 .200 .030 .375 .75 1.50 .75 1.50 II-201 .500 .375 .030 .375 .75 1.40 .75 1.40 II-210 .625 .230 .030 .375 .78 1.10 .78 1.10 II-211 .625 .491 .030 .375 1.00 1.50 1.00 1.50 II-212 .625 .625 .030 .375 NMI NMI NMI NMI II-232 .250 .370 .025 .312 .55 .87 .43 .87
